FEATURES

　　z Three Terminal Adjustable or Fixed Voltages* 1.2V, 1.8V,

　　2.5V, 2.85V, 3.3V, 5.0V and ADJ

　　z Output Current of 800mA

　　z Operates Down to 1V Dropout

　　z Line Regulation: 0.2% Max.

　　z Load Regulation: 0.4% Max.

　　z SOT-223 and TO-252.SOT-89 package available

　　APPLICATIONS

　　z High Efficiency Linear Regulators

　　z Post Regulators for Switching Supplies

　　z 5V to 3.3V Linear Regulator

　　z Battery Chargers

　　z Active SCSI terminators

　　z Power Management for Notebook

　　z Battery Powered Instrumentation

　　GENERAL DESCRIPTION

　　The AMS1117 series of adjustable and fixed voltage regulators are designed to provide 800mA output current and to operate down to

　　1V input-to-output differential. The dropout voltage of the device is guaranteed maximum 1.3V at maximum output current, decreasing

　　at lower load currents.

　　On-chip trimming adjusts the reference voltage to 1%. Current limit is also trimmed, minimizing the stress under overload conditions on

　　both the regulator and power source circuitry.

　　The AMS1117 devices are pin compatible with other three-terminal SCSI regulators and are offered in the low profile surface mount

　　SOT-223 package and in the TO-252 (DPAK) plastic package.
