SFS2305F
SFS2307采用先进的沟槽技术与设计，可实现优异的栅极电荷（RDS）特性（导通状态），同时保持低栅极电荷。该器件适用于多种应用场景。应用于直流-直流转换器负载开关
VDS=-18V，ID=-8A RDS(on)
电压类型：19mΩ@ VGS=-4.5V
电压类型：25mΩ@ VGS=-2.5V
电压类型：19mΩ@ VGS=-4.5V
电压类型：25mΩ@ VGS=-2.5V
