LP6260

Ultra low IQ Synchronous Boost Convertor
The LP6260 device is a synchronous boost convertor with ultra-low quiescent current. It features a true-shutoff function that disconnects the input and output during shutdown and output short-circuit conditions. The LP6260 only consumes 1uA quiescent current under light load condition and can achieve up to 75% efficiency at 20uA load. It can achieve up to 93% efficiency at 200mA load from 3.3 V to 5V conversion.

General Description
The LP6260 device is a synchronous boost convertor  with ultra-low quiescent current. It features a  true-shutoff function that disconnects the input and  output during shutdown and output short-circuit  conditions. The LP6260 only consumes 1uA quiescent current  under light load condition and can achieve up to 75%  efficiency at 20uA load. It can achieve up to 93%  efficiency at 200mA load from 3.3 V to 5V conversion.
Features
5.1V output voltage
Up to 95% efficiency
Output to Input Disconnect at Shutdown Mode
Shut-down current:<0.1uA
Over Output Voltage Protection
Over Current Protection
Over Temperature Protection
Internal Compensation of Soft-start
1.2MHz fixed frequency switching
Applications
Tablet, MID
Smart Phone
Power Bank
