XT9701 是一款只有 150mΩ 导通电阻，应用于 USB 供 电的电源开关电路。内置电荷泵升压来驱动 NMOS 功率管， 当处于关断状态时通过寄生的反向体二极管来消除开关的反 向导通电流。低的静态功耗（23µA）和小封装（SOT-23-5） 特别适合电池供电的便携式设备使用。 保护电路包括防止上电过程中的涌入电流的软启电路， 过流保护的电流分为 900mA 和 600mA 两种，内置热关断保 护电路以及短路保护电路。

The LN9703 is a low voltage, high performance single N-MOSFET power switch, designed for power rail on/off control with low RDS(ON)≈70mΩ and full protection functions. The LN9703 equipped with a charge pump circuitry to drive the internal MOSFET switch and a flag output is available to indicate fault conditions against large di/dt which may cause the supply to fall out of regulation. In order to fit different application, an ISET pin is offered for current limit point setting, a resistor from ISET to ground sets the current limit for the switch. Additional features include soft-start to limit inrush current during plug-in, thermal shutdown to prevent catastrophic switch failure from high-current loads, Output anti back irrigation Protection whether EN pin is connected GND or VIN, under-voltage lockout (UVLO) to ensure that the device remains off unless there is a valid input voltage present, a precision resistor-programmable output current limit up to 3.5A. Besides, the lower quiescent current as 40μA making this device ideal for portable battery-operated equipment. The LN9703 is available in SOT23-5 or SOP-8 package requiring minimum board space and smallest components.

LN9701 是一款只有 100mΩ 导通内阻，应用于 USB 供 电的电源开关电路。内置电荷泵升压来驱动 NMOS 功率管， 当处于关断状态时通过寄生的反向体二极管来消除开关的反 向导通电流。低的静态功耗（23µA）和小封装（SOT23-5L） 特别适合电池供电的便携式设备使用。 保护电路包括防止上电过程中的涌入电流的软启电路， 1.1A/1.3A 过流保护电路是 USB 电源必须的，内置热关断保 护电路以及短路保护电路。
